Name: JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-6.0B-SC
Availability: InStock

Do domu > produkty > gumowy amortyzator >

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

Miejsce pochodzenia:

Chiny

Nazwa handlowa:

Hoan

Numer modelu:

JZP-6.0B-SC

Skontaktuj się z nami

Poproś o wycenę

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Szczegóły produktu

Częstotliwość izolacji:

5Hz

Trwałość:

Wysoki

Zakres temperatur:

Szeroki

Stosowanie:

Absorbowanie wstrząsów i wibracji

Kolor:

Czarny

Certyfikacja produktu:

ISO 9001

Zakres obciążenia:

6,7 KG

Zastosowanie:

Samochody, maszyny, silniki

Słowa kluczowe produktu:

Izolatory tłumiące tarcie

Typ instalacji:

Poziome/pionowe

Koszt:

Przystępny

Typ marketingu:

Gorący produkt 2024

Częstotliwość rezonansu:

30 Hz

Lokalizacja salonu:

Nic

Podkreślić:

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

Warunki płatności i wysyłki

Minimalne zamówienie

Zasady płatności

L/C, D/A, D/P, T/T, Western Union, MoneyGram

ZAŁĄCZONE PRODUKTY

JZP-5.5B-SC Rubber Shock Absorber with Vibration Frequency 5-50Hz and Max Static Load 5.5Kg in 3-24 Inches Length

Najlepszą cenę

JZP-5.0B-SC Rubber Shock Absorber with 10Hz to 100Hz Frequency Range High Vibration Resistance for On-Vehicle Efficiency Validation New Product 2025

Najlepszą cenę

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

Najlepszą cenę

JZP-3.5B-SC Modular Rubber Shock Absorber with 5-6KG Load Range 1:2 Compression Ratio and 40g/11ms Shock Resistance

Najlepszą cenę

Skontaktuj się z nami

86-29-88292913

Skontaktuj się teraz

Opis produktu

JZP-6.0B-SC High-Performance Vibration Isolation and Condition Monitoring for Rubber Shock Absorber

JZP-B-SC Series

Towards the Future: Development Prospect of the JZP Series and Intelligent Vibration Isolation Technology

Technology knows no bounds. Xi'an Hoan Microwave Co., Ltd. continues to invest heavily in R&D, focusing on emerging demands for future on-vehicle vibration isolation technology. The JZP Series platform is evolving towards smarter, more integrated, and more active solutions.

Intelligent Vibration Isolation and Condition Monitoring

Future generations of the JZP Series may integrate micro MEMS accelerometers and IoT modules, enabling real-time monitoring of vibration isolation status and equipment vibration magnitude. This data can be uploaded to cloud platforms via wireless networks, supporting predictive maintenance, fleet management optimization, and vehicle Prognostics and Health Management (PHM).

Active and Semi-Active Vibration Isolation Technologies

For ultra-high vibration isolation requirements—such as on-vehicle lithography machines and quantum communication devices—Xi'an Hoan is exploring active/semi-active vibration isolation technologies. Using sensors, controllers, and actuators, this system can achieve precise control over specific frequency vibrations, especially low-frequency ones.

Dimension Parameter Table

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	B (mm)
JZP-B-SC	46	30	21	40	50	M4	∅5.5	5	22

Technical Parameter Table

Model	Nominal Load (kg)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Valid Period (year)
JZP-1.0B-SC	1.0	≤0.3	-45～+65	41.5±5	100G12times	8
JZP-1.5B-SC	1.5
JZP-2.0B-SC	2.0
JZP-2.5B-SC	2.5
JZP-3.0B-SC	3.0
JZP-3.5B-SC	3.5
JZP-4.0B-SC	4.0
JZP-5.0B-SC	5.0
JZP-5.5B-SC	5.5
JZP-6.0B-SC	6.0

Vibration and Impact Curve of JZP-B-SC Series

Vibration

Impact
